We reported two days ago about the new Onkyo models with support for Dolby ATMOS. Now, it is Yamaha`s turn to launch the same option for two of their receivers.
Yamaha launches xx40 generation of its AVENTAGE Series. The two largest models will support Dolby ATMOS.
AVETNTAGE is the top line of receivers from Yamaha. It is natural to divide the series into two parts, where the RX-A740 and RX-A840 represents models in the middle class, while the three models RX-A1040, RX-A2040 and RX-A3040 can be defined as top class models. And there are the two largest of those that is receiving support for Dolby ATMOS, in the form of a software update later this fall.
But we start with the smaller models. We can of course recognise the upgrades we reported about the new budget series earlier this spring . It's all about WiFi and Wireless Direct, which allows for direct network outside any home network. And it is also about the improved room correction YAPO R.S.C., and Virtual Cinema Front. From RX-A840 and upwards it is furthermore multipoint measurements in YAPO R.C.S. We speak of course of the latest HDMI 2.0 and upgrades necessary to support 4k.
It is also interesting to note that we now must up to RX-A1040 to get analog 7.1 inputs. This underlines the analog multichannel inputs are in retreat, a trend we also see from competing manufacturers.
It is the RX-A2040 and RX-A3040 that allows for Dolby ATMOS. This will not be delivered from the start, but as a software upgrade. RX-A2040 is a 9.2.-amplifier, and has pre-out for 7.2. Depending on flexibility in configuring the pre-out, it appears as somewhat unclear whether this model can be a full 7.2.4 configuration, or if there is talk of a so-called ATMOS-ready solution, for example. 7.2.2. This, of course also depending on whether the processor has 11 channels.
For RX-A3040 however, there is less doubt that it could be a 7.2.4 setup with ATMOS, since this has pre-out in 11.2 even if it is only 9 power amplifiers. An external two-channel power amplifier may fullfill this. RX-A3040 is otherwise the only model with 32-bit DACs for the seven main channels.
So far we have no information on pricing for the new AVENTAGE models, but there is little reason to assume that they differ significantly from the respective models they supersede.
Below we have taken out a comparative statement of the specifications of the five AVENTAGE models from Yamaha's web pages ..
Amplifier Section |
||||||||||
Product Name |
|
|
|
|
|
|||||
Channel |
09.feb |
09.feb |
07.Feb |
07.Feb |
07.Feb |
|||||
Rated Output Power (1kHz, 1ch driven) |
230W (4ohms, 0.9% THD [European Model]) |
220W (4ohms, 0.9% THD [European Model]) |
170W (4ohms, 0.9% THD [European Model]) |
160W (4ohms, 0.9% THD [European Model]) |
150W (4ohms, 0.9% THD [European Model]) |
|||||
Rated Output Power (20Hz-20kHz, 2ch driven) |
150W (8ohms, 0.06% THD) |
140W (8ohms, 0.06% THD) |
110W (8ohms, 0.06% THD) |
100W (8ohms, 0.09% THD) |
90W (8ohms, 0.09% THD) |
|||||
Maximum Effective Output Power (1kHz, 1ch driven) (JEITA) |
230W (8ohms, 10% THD) |
220W (8ohms, 10% THD) |
165 W (8ohms, 10% THD) |
160W (8ohms, 10% THD) |
150W (8ohms, 10% THD) |
|||||
Dynamic Power per Channel (8/6/4/2 ohms) |
175/220/295/410 W |
165/210/285/405 W |
135/165/210/280 W |
130/170/195/240 W |
125/165/190/235 W |
|||||
Surround Sound Processing |
||||||||||
|
|
|
|
|
|
|||||
CINEMA DSP |
Yes (HD3) |
Yes (3D) |
Yes (3D) |
Yes (3D) |
Yes (3D) |
|||||
DSP Programs |
23 |
23 |
17 |
17 |
17 |
|||||
Dialog Level Adjustment |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Virtual Presence Speaker |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Dialogue Lift |
Yes (no presence speakers required) |
Yes (no presence speakers required) |
Yes (no presence speakers required) |
Yes (no presence speakers required) |
Yes (no presence speakers required) |
|||||
SILENT CINEMA / Virtual CINEMA DSP |
Yes (Virtual CINEMA FRONT) |
Yes (Virtual CINEMA FRONT) |
Yes (Virtual CINEMA FRONT) |
Yes (Virtual CINEMA FRONT) |
Yes (Virtual CINEMA FRONT) |
|||||
Dolby TrueHD |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Dolby Digital Plus |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Dolby Pro Logic IIx |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
DTS-HD Master Audio |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Audio Features |
|
|
|
|
|
|||||
Pure Direct |
Yes (video with on mode) |
Yes (video with on mode) |
Yes (video with on mode) |
Yes (video with on mode) |
Yes (video with on mode) |
|||||
Compressed Music Enhancer |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
YPAO sound optimization |
- |
- |
- |
- |
Yes (RSC) |
|||||
YPAO multi-point measurement |
Yes with RSC (Reflected Sound Control), 3D and Angle measurement |
Yes (RSC) |
Yes (RSC) |
Yes (RSC) |
- |
|||||
High-resolution Music Enhancer |
Yes |
Yes |
- |
- |
- |
|||||
YPAO Volume |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Adaptive DRC (Dynamic Range Control) |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Initial Volume & Maximum Volume Setting |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
ART Wedge |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Bi-amp capability |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Audio Delay |
Yes (0-500 ms) |
Yes (0-500 ms) |
Yes (0-500 ms) |
Yes (0-500 ms) |
Yes (0-500 ms) |
|||||
192kHz/24-bit DACs for all channels |
ESS SABRE32 Ultra DAC (for main 7 channels) |
Yes (ESS) |
Yes (ESS) |
Yes (Burr-Brown) |
Yes (Burr-Brown) |
|||||
Video Features |
|
|
|
|
|
|||||
4K Ultra HD Pass-through and upscaling |
||||||||||
HDMI 3D pass-through |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
HDMI Audio Return Channel |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
HDMI upscaling |
Yes (Analogue two HDMI / HDMI dual HDMI) |
Yes (Analogue two HDMI / HDMI dual HDMI) |
Yes (Analogue two HDMI / HDMI dual HDMI) |
Yes (Analogue two HDMI / HDMI dual HDMI) |
Yes (Analogue two HDMI / HDMI dual HDMI) |
|||||
Deep Color/xvColor/24Hz Refresh Rate / Auto Lip-Sync |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Video adjustment |
Yes |
Yes |
- |
- |
- |
|||||
Connectivity |
||||||||||
HDMI Input / Output |
||||||||||
HDMI CEC |
Yes (SCENE, Device Control) |
Yes (SCENE, Device Control) |
Yes (SCENE, Device Control) |
Yes (SCENE, Device Control) |
Yes (SCENE, Device Control) |
|||||
MHL Support |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
USB Input |
iPod / iPhone / iPad, USB Memory, Portable Audio Player |
iPod / iPhone / iPad, USB Memory, Portable Audio Player |
iPod / iPhone / iPad, USB Memory, Portable Audio Player |
iPod / iPhone / iPad, USB Memory, Portable Audio Player |
iPod / iPhone / iPad, USB Memory, Portable Audio Player |
|||||
Network Port |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Wi-Fi |
Yes (with Wireless Direct) |
Yes (with Wireless Direct) |
Yes (with Wireless Direct) |
Yes (with Wireless Direct) |
Yes (with Wireless Direct) |
|||||
AirPlay |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Front AV Input |
HDMI (MHL support) / USB / Analogue Audio / Composite |
HDMI (MHL support) / USB / Analogue Audio / Composite |
HDMI (MHL support) / USB / Analogue Audio / Composite |
HDMI (MHL support) / USB / Analogue Audio / Composite |
HDMI (MHL support) / USB / Composite |
|||||
DC Out |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Digital Audio Input / Output: Optical |
3/0 |
3/0 |
3/0 |
2/0 |
2/0 |
|||||
Digital Audio Input / Output: Coaxial |
3/0 |
3/0 |
3/0 |
2/0 |
2/0 |
|||||
Analog Audio Input / Output |
10 (front 1) / 1 |
10 (front 1) / 1 |
10 (front 1) / 1 |
06.jan |
04.jan |
|||||
Phono Input |
Yes |
Yes |
Yes |
Yes |
- |
|||||
Component Video Input / Output |
03.jan |
03.jan |
03.jan |
02.jan |
02.jan |
|||||
Composite Video Input / Output |
5 (front 1) / 2 |
5 (front 1) / 2 |
5 (front 1) / 2 |
5 (front 1) / 2 |
5 (front 1) / 2 |
|||||
Preout |
11.2ch |
7.2ch |
7.2ch |
7.2ch |
SW (2 x mono) |
|||||
Multi-Channel Input |
8ch |
8ch |
8ch |
- |
- |
|||||
Headphone Output |
1 |
1 |
1 |
1 |
1 |
|||||
Tuner Section |
|
|
|
|
|
|||||
FM / AM Tuner |
||||||||||
User Interface |
|
|
|
|
|
|||||
On-screen display |
Graphical User Interface |
Graphical User Interface |
Graphical User Interface |
Graphical User Interface |
Graphical User Interface |
|||||
SCENE |
SCENE PLUS (12 sets) |
SCENE PLUS (12 sets) |
SCENE PLUS (12 sets) |
SCENE (4 sets) |
SCENE (4 sets) |
|||||
App Control |
Yes (iPhone / iPad / Android phone / tablet) |
Yes (iPhone / iPad / Android phone / tablet) |
Yes (iPhone / iPad / Android phone / tablet) |
Yes (iPhone / iPad / Android phone / tablet) |
Yes (iPhone / iPad / Android phone / tablet) |
|||||
Web Browser Control |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Remote Control Unit |
Yes (Preset) |
Yes (Preset) |
Yes (Preset) |
Yes (Preset) |
Yes |
|||||
Zone Control |
|
|
|
|
|
|||||
Zone 2 Audio Output |
Preout / HDMI |
Preout / HDMI |
Preout / HDMI |
Line output |
Line output |
|||||
Powered Zone |
Zone 2/3 |
Zone 2/3 |
Zone 2 |
Zone 2 |
Zone 2 |
|||||
+12 V Trigger Output |
2 |
2 |
2 |
1 |
1 |
|||||
Remote (IR) Input / Output |
02.feb |
02.feb |
01.jan |
01.jan |
01.jan |
|||||
Zone B Output |
HDMI |
HDMI |
HDMI |
Yes (HDMI) |
- |
|||||
Zone Video Output |
HDMI / Component / Composite |
HDMI / Component / Composite |
HDMI / Component / Composite |
- |
- |
|||||
RS-232C Interface |
Yes |
Yes |
Yes |
Yes |
- |
|||||
Zone 3 Audio Output |
Preout |
Preout |
- |
- |
- |
|||||
Zone HDMI |
Yes (Advanced Zone HDMI Switching) |
Yes (Advanced Zone HDMI Switching) |
Yes (HDMI Zone Switching) |
- |
- |
|||||
Zone 4 Audio Output |
HDMI |
HDMI |
- |
- |
- |
|||||
Party Mode |
Yes |
Yes |
Yes |
- |
- |
|||||
Zone GUI |
YES |
YES |
- |
- |
- |
|||||
General |
|
|
|
|
|
|||||
Standby Power Consumption (IR only) |
||||||||||
Auto Power Standby |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
ECO mode |
Yes |
Yes |
Yes |
Yes |
Yes |
|||||
Dimensions (W x H x D) |
435 x 192 x 467 mm (with antenna: 435 x 252 x 474 mm); 17-1/8 "x 7-1/2" x 18-3/8 "(with antenna: 17-1/8" x 9-7/8 "x 18-5/8") |
435 x 192 x 467 mm (with antenna: 435 x 252 x 474 mm); 17-1/8 "x 7-1/2" x 18-3/8 "(with antenna: 17-1/8" x 9-7/8 "x 18-5/8") |
435 x 182 x 432 mm (with antenna: 435 x 242 x 439 mm); 17-1/8 "x 7-1/8" x 17 "(with antenna: 17-1/8" x 9-1/2 "x 17-1/4") |
435 x 171 x 369 mm (with antenna: 435 x 234 x 382 mm); 17-1/8 "x 6-3/4" x 14-1/2 "(with antenna: 17-1/8" x 9-1/4 "x 15") |
435 x 171 x 367 mm (with antenna: 435 x 234 x 380 mm); 17-1/8 "x 6-3/4" x 14-1/2 "(with antenna: 17-1/8" x 9-1/4 "x 15") |
|||||
Weight |
19.6 kg; 43.2 lbs. |
17.0 kg; 37.5 lbs. |
14.9 kg; 32.8 lbs. |
10.6 kg; 23.4 lbs. |
10.5 kg; 23.2 lbs. |
Read more about the new ADVENTAGE models at Yamaha`s webpages:
- RX-A740
- RX-A840
- RX-A1040
- RX-A2040
- RX-A3040
