Meridian Explorer 2 – MQA ready. Oppdatert

Skrevet av

Den 4. desember avduket Meridian sitt nye lydformat MQA. De hadde åpenbart jobbet i kulissene med et kompatibelt produkt også.

Den 5. desember ble det kunngjort at Meridian sin lommeDAC Explorer får sin oppfølger – Meridian Explorer 2. Og denne er allerede klargjort for MQA-dekoding.



Explorer 2 er i likhet med forgjengeren en asynkron USB-DAC i svært kompakt fomat. Den har en USB-mini type B inngang, og av utganger kan du velge mellom 35mm jack med fixed gain, eller en hodeltelefonutgang med variabel gain. Vi har tidligere nevnt MQA, og i tillegg har den også Meridian sitt egen Apodising Filter som spesielt skal forhindre pre-ringing.

Meridian Explorer 2 kan benyttes mot disse operativsystemene:

Macintosh OS X 10.6.4 (Snow Leopard) or later.
Windows XP SP3, Windows 7 SP1, Windows 8 or later
Linux kernel 2.6.37 or later and ALSA version 1.0.32 or greater.





Info fra produsent:



Product highlights

True Meridian quality from a pocket Digital to Analogue Converter
Includes USB DAC and Headphone Amplifier
Meridian MQA Decoding and Rendering with LEDs to indicate authenticated master-quality replay
Full range of Meridian Resolution Enhancement technologies for ultimate performance: Apodising filter, 4x upsampling to 176.4/192kHz, Noise Shaping
Asynchronous USB Audio Class Compliant 2.0 HS 480Mb/s for best-in-class performance
Bus-powered; plugs into any computer with a USB port
Exceptionally high resolution (24-bit/192kHz)
6-layer circuit board with audiophile-grade components throughout
Auto-sensing headphone and 192kHz-derived fixed analogue outputs
Advanced headphone volume control: 0 to –100dB, ideal for sensitive headphones.
Ultimate playback performance limited only by the source material – makes any file sound its best
Compact, elegant and rugged metal enclosure
Cable connection to avoid motherboard stress
Hand made in the UK

Outline Specifications

Inputs
• USB mini type B.Outputs
• 3.5mm analogue line out, fixed 2v RMS.
• 3.5mm headphone jack with variable-level output, impedance 0.47Ω.Construction
• Extruded Aluminium shell with moulded plastic endcaps and rubber foot.Power
• USB, nominal 5V at <500mA.Processing
• Dual Tile XMOS DSP with 16 cores and 1000 MIPS Indicators
• Three white LEDs (1x, 2x, 4x) show connected state and audio stream rate. 1x LED glows white for PCM, green to indicate MQA playback and blue to indicate MQA Studio playback. MQA indications will no  show if the bitstream is altered in any way.Implementation
• USB audio class compliant 2.0 HS 480Mb/s bandwidth.
• Asynchronous: device is the clock source for high quality.
• Firmware upgrade via USB.
• Windows drivers provided, no drivers required for Macintosh OS X or Linux.
• Analogue volume control for headphone output, controlled from PC, control law modified to match connected OS.

OS requirements
• Macintosh OS X 10.6.4 (Snow Leopard) or later
• Windows XP SP3, Windows 7 SP1, Windows 8 or later
• Linux kernel 2.6.37 or later and ALSA version 1.0.32 or greater

Dimensions (approx)
102 x 32 x 18mm (4.0 x 1.25 x 0.7in).
Weight (approx) 50g (1.76oz).



Les mer om Meridian Explorer 2 hos produsenten.



Veil. pris i Norge: kr. 2.500,-

Meridian importeres til Norge av:

MDS Norway AS
Rundtom 68

1385 Asker
